- Place of Origin:CN;GUA
- Sealed Type:Sealed
- Maintenance Type:Free
- Usage:Folklift, Golf buggies,ups battery, solar battery
- Brand Name:CSPOWER
- Model Number:HTD6-420 solar battery
- Weight:57.1 kg
6V420ah golf buggies battery, High temperature Deep Cycle Gel Battery 6V420ah golf buggies battery, High temperature Deep Cycle AGM Battery
1. 3years warranty of solar battery at 35°C average
2. Able to operate at 60°C
3. Cycle usage: 50% DOD, 1200cycles, 30% DOD 2400cycles.
4. Solar battery design Floating Life 25°C: 20 years
5. Self-discharge is 2% ~ 3% per month.
HTD6-420 | |||
6V (3 cells per unit) | |||
Design Floating Life @ 25℃ | 20 Years | ||
Nominal Capacity @ 25℃ | 20 hour rate @ 21.0A, 5.4V | 420Ah | |
Capacity @ 25℃ | 10 hour rate (37.8A, 5.4V) | 378Ah | |
5 hour rate (66.8A, 5.25V) | 334Ah | ||
1 hour rate (233.3A, 4.8V) | 233.3Ah | ||
Internal Resistance | Full Charged Battery @ 25℃ | ≤1.5mΩ | |
Ambient Temperature | Discharge | -25℃~60℃ | |
Charge | -25℃~60℃ | ||
Storage | -25℃~60℃ | ||
Max.Discharge Current | @ 25℃ 1260A(5s) | ||
Capacity affected by Temperature (10 hour ) | 40℃ | 108% | |
25℃ | 100% | ||
0℃ | 90% | ||
-15℃ | 70% | ||
Self-Discharge @25℃per Month | 3% | ||
Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 84A Voltage 6.8 - 6.9V | |
Cycle Use | Initial Charging Current Less than 84A Voltage 7.2 - 7.45V | ||
Dimension (mm*mm*mm) | Length 295±1 * Width 178±1 * Height 404±1 (Total Height 424±1) | ||
Weight (kg) | 57±3% | ||
The HTD deep cycle gel solar battery adopts the advanced developed nano gel electrolyte with super-C additive plus heavy duty plates design inside. It has a longer service life even deep cycle discharge use and can provide optimum and reliable service under extreme condition such as high temperature and frequent power failure, thus it is highly suited for tropical area in outdoor applications such as Telecom BTS stations and Off-grid PV system
Features and Advantages of high temperature deep cycle gel battery
1. Able to operate at 40-60°C
2. Integrated design to ensure the best uniformity and reliability
3. Longer life and higher stability under high temp. environment (no air-con needed)
4. Super-C additives: Deep discharge recovery capability, 1600cycles @50%DOD
CSPOWER BATTERY TECH CO.,LTD is a professional manufacturer and exporter of environmental friendly Rechargeable Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as Solar inverter, Solar charger controller, Solar panel and so on.
Q: Can you print my logo on the battery cover?
A: Yes, OEM is available,we can print your logo on the battery case freely. Welcome to send us your logo design and dicuss with us about the details.
Q: How long is your delivery time?
A: Usually it takes about 10-20 days for production varies with products. Urgent delivery it in 5days
Q: What is your warranty policy?
A: We provide 1 ~ 5 years different warranty.
Q: Why Choose CSPOWER?
A: 1) Nearly 13 years leading manufacturer,all production lines in our factory are automatic and imported from Germany.
2) 20000KWH production capacity to guarantee the best deliver time
3) The good construction warranty - 1-5 years free replacement no need return.
4) Comprehensive certificates approval: CE / ISO / IEC
5) The reasonable and most competitive price without sacrifice of quality.
6) A professional experienced team to provide you high-quality service before and after sale.
