deep cycle lithium battery solar
12V 100Ah deep cycle lithium battery solar has good discharging performance, extended cycle life, and stable performance at high and low temperatures. The deep cycle lithium battery solar is suitable for a wide range of energy storage applications, particularly renewable solar energy systems. The deep cycle lithium battery solar has three-year guarantee at an average temperature of 35°C-40°C with operating temperature range of -40°C to 60°C. The deep cycle lithium battery solar has Longer lifespan and greater stability in high-temperature environments (Perfect to be applied to renewable energy system or hybrid power system at tough condition.) Use lead plates with Super-C additives: Capacity for deep discharge recovery. Use of Deep Cycles: 50% DOD, 1500 Cycles in a high/cold temperature location.
deep cycle lithium battery solar
deep cycle lithium battery solar
- Place of Origin:CN;GUA
- Sealed Type:Sealed
- Maintenance Type:Free
- Usage:ups, solar, inverter, telecom, back-up
- Brand Name:CSPOWER
- Model Number:HTL12-100Ah
- Weight:30.5kg
Solar Storaging Gel Powerwall Specs Incentive
deep cycle lithium battery solar
deep cycle lithium battery solar
| HTL12-100 | |||
| Nominal Voltage | 12V (6 cells per unit) | ||
| Design Floating Life @ 25℃ | 20 Years | ||
| Nominal Capacity @ 25℃ | 20 hour rate@ 21.0A, 5.4V | 100Ah | |
| Capacity @ 25℃ | 10 hour rate (37.8A, 5.4V) | 90Ah | |
| 5 hour rate (66.8A, 5.25V) | 79.5Ah | ||
| 1 hour rate (233.3A, 4.8V) | 55.6Ah | ||
| Internal Resistance | Full Charged Battery@ 25℃ | ≤5.3mΩ | |
| Ambient Temperature | Discharge | -25℃~60℃ | |
| Charge | -25℃~60℃ | ||
| Storage | -25℃~60℃ | ||
| Max.Discharge Current | @ 25℃ 540A(5s) | ||
| Capacity affected by Temperature (10 hour ) | 40℃ | 108% | |
| 25℃ | 100% | ||
| 0℃ | 90% | ||
| -15℃ | 70% | ||
| Self-Discharge@25℃per Month | 3% | ||
| Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 22.5A Voltage 13.6 - 13.8V | |
| Cycle Use | Initial Charging Current Less than 22.5A Voltage 13.6 - 13.8V | ||
| Dimension (mm*mm*mm) | Length 307±1 * Width 169±1 * Height 211±1 (Total Height 216±1) | ||
| Weight (kg) | 30.5±3% | ||
Solar Storaging Gel Powerwall Specs Incentive
Solar Storaging Gel Powerwall Specs Incentive
QC/ Certification
Application
Applications of CSPOWER UPS Free Maintenance Solar Gel Battery 12V (HTL type)
BTS Stations, Solar Wind energy system, UPS system, Golf Cart Electric Wheels, and another power system
CSPOWER 12v 100ah Solar Battery, Strive for Perfection, Time-honored, and Battery Quality is Higher Than the Industry Standard, High-quality Materials, Fine Workmanship, Trustworthy
CSPOWER 12v 100ah Solar Battery, Source Manufacturer, Strength Supply, Unlike Other Battery Manufacturers, We Ensure Comprehensive Quality Control. Mesh Casting, Sheet Pasting and Final Assembly Are All Done in Our Own Manufacturing Plant.
