- Place of Origin:CN;GUA
- Sealed Type:Sealed
- Maintenance Type:Free
- Usage:Golf cart, Tour bus, Forklift, Sweeper, Floor cleaning machine
- Brand Name:CSPOWER
- Model Number:HTD6-220 agm battery
- Weight:31.5kgs agm battery
China manufacturer Deep Cycle lead acid bateria 6V 220ah Deep Cycle AGM battery
Deep Cycle AGM Bateria 6v 220ah Sealed Heavy Duty Motive Battery
1.3 years warranty at 25°C average
2. Able to operate at 60°C
3. Cycle usage: 50% DOD, 1500 cycles, 30% DOD 2200 cycles.
4. Design Floating Life 25°C: 20 years
5. Self-discharge is 2% ~ 3% per month.
| HTD6-220 | ||||
| Nominal Voltage | 6V (3 cells per unit) | |||
| Design Floating Life @ 25℃ | 20 Years | |||
| Nominal Capacity @ 25℃ | 20 hour rate @ 21.0A, 5.4V | 220Ah | ||
| Capacity @ 25℃ | 10 hour rate (37.8A, 5.4V) | 198Ah | ||
| 5 hour rate (66.8A, 5.25V) | 175Ah | |||
| 1 hour rate (233.3A, 4.8V) | 127.1Ah | |||
| Internal Resistance | Full Charged Battery @ 25℃ | ≤2.7mΩ | ||
| Ambient Temperature | Discharge | -25℃~60℃ | ||
| Charge | -25℃~60℃ | |||
| Storage | -25℃~60℃ | |||
| Max.Discharge Current | @ 25℃ 660A(5s) | |||
| Capacity affected by Temperature (10 hour ) | 40℃ | 108% | ||
| 25℃ | 100% | |||
| 0℃ | 90% | |||
| -15℃ | 70% | |||
| Self-Discharge @ 25℃per Month | 3% | |||
| Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 44A Voltage 6.8 - 6.9V | ||
| Cycle Use | Initial Charging Current Less than 44A Voltage 7.2 - 7.45V | |||
| Dimension (mm*mm*mm) | Length 306±1 * Width 168±1 * Height 220±1 (Total Height 225±1) | |||
| Weight (kg) | 31.6±3% | |||
The rechargeable batteries are lead-lead dioxide systems. The dilute sulfuric acid electrolyte is absorbed by separators and plates and thus immobilized. Should the battery be accidentally overcharged producing hydrogen and oxygen, special one-way valves allow the gases to escape thus avoiding excessive pressure build-up. Otherwise, the battery is completely sealed and is, therefore, maintenance-free, leak proof and usable in any position.
Features and Advantages of Deep Cycle VRLA AGM Solar battery
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to
99% and freedom from electrolyte maintenance or water adding.
1. Not restricted for air transport-complies with IATA/ICAO Special Provision A67.
2. UL-recognized component.
3. Can be mounted in any orientation.
4. Computer designed lead, calcium tin alloy grid for high power density.
5. Long service life, float or cyclic applications.
6. Maintenance-free operation.
Wholesale 6v heavy duty battery choose CSPOWER：
Many years of 6v heavy duty battery manufacturing and research and development experience, trustworthy, fast delivery, reliable quality, easy to use, excellent performance, long life, strong power, excellent raw materials, forging ingenious 6v heavy duty battery, high conductivity, and lasting stability.
