- Brand Name:CSPOWER
- Usage:UPS systems, Inverter;Solar&Wind; Emergency Power Systems;Telecom
- Place of Origin:CN;GUA
- Voltage:12v
- Sealed Type:Sealed
- Maintenance Type:Free
- Model Number:CS12-180
- Size:532*206*215*219(mm)
- Weight:53kg/PC
- Nominal Capacity:180AH
1. CSPOWER Deep Cycle storage battery structure
2. CSPOWER CS12-180 VRLA Deep Cycle AGM Battery specificaiton
CS12-180 | |||
Nominal Voltage | 12V (6 cells per unit) | ||
Design Floating Life @ 25℃ | 10 Years | ||
Nominal Capacity @ 25℃ | 10 hour rate @18.0A,10.8V | 180Ah | |
Capacity @ 25℃ | 20 hour rate (9.99A, 10.8V) | 199.8Ah | |
5 hour rate (32.9A, 10.5V) | 164.5Ah | ||
1 hour rate (119.8A,9.6V) | 119.8Ah | ||
Internal Resistance | Full Charged Battery @ 25℃ | ≤3.0mΩ | |
Ambient Temperature | Discharge | -15℃~45℃ | |
Charge | -15℃~45℃ | ||
Storage | -15℃~45℃ | ||
Max.Discharge Current | @ 25℃ 1080A(5s) | ||
Capacity affected by Temperature (10 hour ) | 40℃ | 105% | |
25℃ | 100% | ||
0℃ | 85% | ||
-15℃ | 65% | ||
Self-Discharge @25℃per Month | 3% | ||
Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 45A Voltage 13.6-13.8V | |
Cycle Use | Initial Charging Current Less than 45A Voltage 14.4-14.9V | ||
Dimension (mm*mm*mm) | Length 532±1 * Width 206±1 * Height 216±1 (Total Height 222±1) | ||
Weight (kg) | 53±3% | ||
This Solar Panel Sealed Lead Acid Battery Adopts Advanced Ultra-fine Glass Wool (agm) Separator is Used to Make All the Electrolyte Adsorbed in the Electrode Plate and the Separator. the Gas Compounding Efficiency is High, No Acid Mist Escapes, and No Equipment is Corroded.
Advanced Process Formula and Strict Process Control Ensure That Battery Products Have Sufficient Capacity and Uniform and Reliable Overall Performance. Wholesale Solar Panel Sealed Lead Acid Battery Choose CSPOWER.
