Maintenance Type:Free
Certification:UL
Weight:16kgs deep cycle battery
Certification:ce
Brand Name:CSPOWER
Model Number:HTD12-55 deep cycle battery
Place of Origin:CN;GUA
Sealed Type:Sealed
Usage:Golf cart, Tour bus, Forklift, Sweeper, Floor cleaning machine
China manufacturer Maintenance Free Bateria 12v 55ah Deep Cycle AGM Lead Acid Battery
12v AGM Golf Cart Batteries 55ah Deep Cycle VRLA Lead Acid Battery for Pump/ Golf Cart
--- For UPS/Electronic toy/Alarm system
1.3 years warranty at 25°C average
2. Cycle usage: 50% DOD, 1200cycles, 30% DOD 2200 cycles.
3. Design Floating Life 25°C: 15-20 years
4. Self-discharge is 2% ~ 3% per month.
5. Able to operate at 60°C
Product Overviews
Product Description
HTD12-55 | |||
Nominal Voltage | 12V (6 cells per unit) | ||
Design Floating Life @ 25℃ | 15 Years | ||
Nominal Capacity @ 25℃ | 20 hour rate@ 21.0A, 5.4V | 55Ah | |
Capacity @ 25℃ | 10 hour rate (37.8A, 5.4V) | 50Ah | |
5 hour rate (66.8A, 5.25V) | 44Ah | ||
1 hour rate (233.3A, 4.8V) | 33.6Ah | ||
Internal Resistance | Full Charged Battery@ 25℃ | ≤10mΩ | |
Ambient Temperature | Discharge | -25℃~60℃ | |
Charge | -25℃~60℃ | ||
Storage | -25℃~60℃ | ||
Max.Discharge Current | @ 25℃ 330A(5s) | ||
Capacity affected by Temperature (10 hour ) | 40℃ | 108% | |
25℃ | 100% | ||
0℃ | 90% | ||
-15℃ | 70% | ||
Self-Discharge@25℃per Month | 3% | ||
Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 12.5A Voltage 13.6 - 13.8V | |
Cycle Use | Initial Charging Current Less than 12.5A Voltage 13.6 - 13.8V | ||
Dimension (mm*mm*mm) | Length 229±1 * Width 138±1 * Height 208±1 (Total Height 212±1) | ||
Weight (kg) | 16.2±3% | ||
The rechargeable batteries are lead-lead dioxide systems. The dilute sulfuric acid electrolyte is absorbed by separators and plates and thus immobilized. Should the battery be accidentally overcharged producing hydrogen and oxygen, special one-way valves allow the gases to escape thus avoiding excessive pressure build-up. Otherwise, the battery is completely sealed and is, therefore, maintenance-free, leak proof and usable in any position.
Features and Advantages of Deep Cycle VRLA AGM Lead Acid battery
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to
99% and freedom from electrolyte maintenance or water adding.
1. Not restricted for air transport-complies with IATA/ICAO Special Provision A67.
2. UL-recognized component.
3. Can be mounted in any orientation.
4. Computer designed lead, calcium tin alloy grid for high power density.
5. Long service life, float or cyclic applications.
6. Maintenance-free operation.
QC process
This 12v AGM Golf Cart Batteries,
Stronger Cyclic Charging Ability and Longer Service Life
Higher Capacitance Stability Throughout the Life Cycle
Excellent Raw Materials, Provide High-quality Batteries, Add Active Materials to the Plates to Improve the Charge Acceptance Performance; Delay the Sulfation of the Negative Electrode, and the High Conductivity is Stable.
