Technical Specs Loop Solar Powerwall Inverter
Technical Specs Loop Solar Powerwall Inverter
Technical Specs Loop Solar Powerwall Inverter has good discharging performance, extended cycle life, and stable performance at high and low temperatures. Technical Specs Loop Solar Powerwall Inverter is suitable for a wide range of energy storage applications, particularly renewable solar energy systems. Technical Specs Loop Solar Powerwall Inverter has a three-year warranty at an average temperature of 35°C to 40°C. Technical Specs Loop Solar Powerwall Inverter has proven ability to work from -40°C to 60°C. Cycle usage: 50% DOD, 1500 Cycles work in high/cold temp. area.Use super-C additives lead plates: Deep discharge recovery capability
Technical Specs Loop Solar Powerwall Inverter
- Place of Origin:CN;GUA
- Voltage:12v
- Sealed Type:Sealed
- Maintenance Type:Free
- Usage:ups, solar, inverter, telecom, back-up
- Brand Name:CSPOWER
- Model Number:HTL12-14Ah
- Size:152*99*96*102mm
- Weight:4.1
- Nominal Capacity:14Ah
Technical Specs Loop Solar Powerwall Inverter Description
| HTL12-24 | |||
| Nominal Voltage | 12V (6 cells per unit) | ||
| Design Floating Life @ 25℃ | 20 Years | ||
| Nominal Capacity @ 25℃ | 20 hour rate @ 6A, 10.8V | 24Ah | |
| Capacity @ 25℃ | 10 hour rate (3.6A, 10.8V) | 22Ah | |
| 5 hour rate (6.4A, 10.5V) | 19Ah | ||
| 1 hour rate (24.4A, 9.6V) | 14.7Ah | ||
| Internal Resistance | Full Charged Battery @ 25℃ | ≤12mΩ | |
| Ambient Temperature | Discharge | -25℃~60℃ | |
| Charge | -25℃~60℃ | ||
| Storage | -25℃~60℃ | ||
| Max.Discharge Current | @ 25℃ 800A(5s) | ||
| Capacity affected by Temperature (10 hour ) | 40℃ | 108% | |
| 25℃ | 100% | ||
| 0℃ | 90% | ||
| -15℃ | 70% | ||
| Self-Discharge @25℃per Month | 3% | ||
| Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 5.4A Voltage 13.6 - 13.8V | |
| Cycle Use | Initial Charging Current Less than5.4A Voltage 14.4 - 14.9V | ||
| Dimension (mm*mm*mm) | Length 407±1 * Width 173±1 * Height 283±1 (Total Height 226±1) | ||
| Weight (kg) | 45.7±3% | ||
GEL Structure
Technical Specs Loop Solar Powerwall Inverter
Technical Specs Loop Solar Powerwall Inverter QC/ Certification
Application
Why Wholesale 12v Battery for Solar Charging Choose CSPOWER?
Factory Direct Selling, Eliminating All Intermediate Links, and Transfer the Profits to You.
Excellent Craftsmanship, Just for Safety.
12v Battery for Solar Charging Adopt Ultra-conventional Design, Life Span of 5-8 Years, Strong Mechanical Strength, Corrosion Resistance.
