- Place of Origin:CN;GUA
- Sealed Type:Sealed
- Maintenance Type:Free
- Usage:solar system, ups system, telecom system
- Brand Name:CSPOWER
- Model Number:OPzV2-1500 OPzV battery
- Weight:112 kgs OPzV Battery
Super Long Life 2V 1500ah OPzV Tubular GEL Solar Battery
2. Able to operate at 60°C
3. Cycle usage: 50% DOD, 3500cycles, 30% DOD 5500cycles.
4. Solar battery design Floating Life 25°C: 25 years
5. Self-discharge is 2% ~ 3% per month.
Nominal Voltage | 2V(Single Cell) | ||
Design Floating Life @ 25℃ | 25 Years | ||
Nominal Capacity @ 25℃ | 10 hour rate @150.0A,1.8V | 1500Ah | |
Capacity @ 25℃ | 20hour rate (78.75A,1.8V ) | 1575Ah | |
5 hour rate (255A,1.75V ) | 1275Ah | ||
1 hour rate (948A,1.6V ) | 948Ah | ||
Internal Resistance | Full Charged Battery @ 25℃ | ≤0.23mΩ | |
Ambient Temperature | Discharge | -40℃~70℃ | |
Charge | -0℃~50℃ | ||
Storage | -20℃~60℃ | ||
Max.Discharge Current | @ 25℃ 4500A(5s) | ||
Capacity affected by Temperature (10 hour ) | 40℃ | 105% | |
25℃ | 100% | ||
0℃ | 89% | ||
-15℃ | 79% | ||
Self-Discharge @25℃per Month | 2% | ||
Charge (Constant Voltage) @ 25℃ | Standby Use | Initial Charging Current Less than 300.0A Voltage 2.25-2.3V | |
Cycle Use | Initial Charging Current Less than 300.0A Voltage 2.37-2.4V | ||
Dimension (mm*mm*mm) | Length 275±1 * Width 210±1 * Height 795±1 (Total Height 831±1) | ||
Weight (kg) | 117±3% | ||
CSPOWER OPzV series Tubular GEL battery is with 25 years floating design life, it is a Valve Regulated Tubular Gel battery that adopts immobilized GEL and Tubular Plate technology to offer high reliability and performance. The Battery is designed and manufactured according to DIN standards and with die-casting positive grid and patent formula of active material. OPzV series exceeds DIN standard values with more than 25 years floating design life at 25℃ and is even more suitable for cyclic use under extreme operating conditions.
Features and Advantages of OPzV Tubular Gel battery
1. Able to operate at -40-60°C
2. Integrated design to ensure the best uniformity and reliability
3. Longer life and higher stability under high temp. environment (no air-con needed)
4. Super-C additives: Deep discharge recovery capability, 3500cycles @50%DOD
CSPOWER BATTERY TECH CO.,LTD is a professional manufacturer and exporter of environmental friendly Rechargeable Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as Solar inverter, Solar charger controller, Solar panel and so on.
Q: Can you print my logo on the battery cover?
A: Yes, OEM is available,we can print your logo on the battery case freely. Welcome to send us your logo design and dicuss with us about the details.
Q: How long is your delivery time?
A: Usually it takes about 10-20 days for production varies with products. Urgent delivery it in 5days
Q: What is your warranty policy?
A: We provide 1 ~ 5 years different warranty.
Q: Why Choose CSPOWER?
A: 1) Nearly 13 years leading manufacturer,all production lines in our factory are automatic and imported from Germany.
2) 20000KWH production capacity to guarantee the best deliver time
3) The good construction warranty - 1-5 years free replacement no need return.
4) Comprehensive certificates approval: CE / ISO / IEC
5) The reasonable and most competitive price without sacrifice of quality.
6) A professional experienced team to provide you high-quality service before and after sale.
