Model NO.
HTL12-20
Delivery:
EXW,FCA,FOB,CIF,CFR
Minimum order quantity:
50 pieces
Supply Ability:
100000 pieces / Month
Country of Origin:
Shenzhen/Guangdong/Foshan
Quantity:

Ups Solar Technical Specs Loop Powerwall


Ups Solar Technical Specs Loop Powerwall has good discharging performance, extended cycle life, and stable performance at high and low temperatures. Ups Solar Technical Specs Loop Powerwall is suitable for a wide range of energy storage applications, particularly renewable solar energy systems. Ups Solar Technical Specs Loop Powerwall is maintenance-free, carried with valve-sealed construction with no free electrolyte. Ups Solar Technical Specs Loop Powerwall has a three-year warranty at an average temperature of 35°C to 40 °C. Ups Solar Technical Specs Loop Powerwall has proven ability to operate at -40°C to 60°C.


Ups Solar Technical Specs Loop Powerwall

  • Place of Origin:CN;GUA
  • Voltage:12v
  • Sealed Type:Sealed
  • Maintenance Type:Free
  • Usage:Folklift, Golf buggies,ups battery, solar battery
  • Brand Name:CSPOWER
  • Model Number:HTL12-20
  • Size:181*77*167*167
  • Weight:6.3
  • Nominal Capacity:20

>>>>>>>>>>>>>>>>>>>>>>>>>>>Contact US



GEL battery (1).PNG

Ups Solar Technical Specs Loop Powerwall Parameters

HTL12-20

Nominal Voltage

12V (6 cells per unit)

Design Floating Life @ 25℃

15 Years

Nominal Capacity @ 25℃

20 hour rate@ 21.0A, 5.4V

20Ah

Capacity @ 25℃

10 hour rate (37.8A, 5.4V)

18Ah

5 hour rate (66.8A, 5.25V)

16Ah

1 hour rate (233.3A, 4.8V)

11.1Ah

Internal Resistance

Full Charged Battery@ 25℃

≤12.0mΩ

Ambient Temperature

Discharge

-15℃~45℃

Charge

-15℃~45℃

Storage

-15℃~45℃

Max.Discharge Current

@ 25℃ 120A(5s)

Capacity affected by Temperature (10 hour )

40℃

105%

25℃

100%

0℃

85%

-15℃

65%

Self-Discharge@25℃per Month

3%

Charge (Constant Voltage) @ 25℃

Standby Use

Initial Charging Current Less than 6A Voltage 13.6 - 13.8V

Cycle Use

Initial Charging Current Less than 6A Voltage 14.4 - 14.9V

Dimension (mm*mm*mm)

Length 181±1 * Width 77±1 * Height 167±1 (Total Height 167±1)

Weight (kg)

6±3%

More capacity details for HTL series, kindly CLICKhere

Ups Solar Technical Specs Loop Powerwall

Advantages for CSPOWER Power Boat Pontoon Electric Trolling Motor Deep Cycle Battery
1. Three years warranty at 35°C-40°C average
2. Able to operate at -40°C to 60°C
3. Longer life and higher stability under high temp. environment (no air-con needed)
4. Use super-C additives lead plates: Deep discharge recovery capability 5. Cycle usage: 50% DOD, 1500 Cycles work in high/cold temp. area._08.pngHTL12-20.JPG
