Model NO.
HTL12-200 deep cycle battery
Delivery:
FOB
Minimum order quantity:
10 pieces
Supply Ability:
100000 pieces / Month
Country of Origin:
Shenzhen/Guangzhou
Quantity:

12v deep cycle solar battery

12v deep cycle solar battery  utilizes a totally encapsulated structure and cutting-edge manufacturing technologies developed in the 1990s. 12v deep cycle solar battery has excellent performance, high durability, minimum pollution, minimal maintenance, and therefore is reliable and dependable. The deep cycle battery for solar storage has three-year guarantee at an average temperature of 35°C-40°C with operating temperature range of -40°C to 60°C. The deep cycle battery for solar storage has Longer lifespan and greater stability in high-temperature environments (Perfect to be applied to renewable energy system or hybrid power system at tough condition.) Use lead plates with Super-C additives: Capacity for deep discharge recovery. Use of Deep Cycles: 50% DOD, 1500-1600 Cycles in a high/cold temperature location.


deep cycle battery for solar storage

  • Place of Origin:CN;GUA

  • Sealed Type:Sealed

  • Maintenance Type:Free

  • Usage:ups, solar, inverter, telecom

  • Brand Name:CSPOWER

  • Model Number:HTL12-200 deep cycle battery

  • Weight:58.7kgs

deep cycle battery for solar storage

high quality a maintenance free battery

Solar Deep Loop Powerwall Specs Incentive

HTL12-200

Nominal Voltage

12V (6 cells per unit)

Design Floating Life @ 25℃

20 Years

Nominal Capacity @ 25℃

20 hour rate @ 21.0A, 5.4V

200Ah

Capacity @ 25℃

10 hour rate (37.8A, 5.4V)

180Ah

5 hour rate (66.8A, 5.25V)

159Ah

1 hour rate (233.3A, 4.8V)

115.5Ah

Internal Resistance

Full Charged Battery @ 25℃

≤3mΩ

Ambient Temperature

Discharge

-25℃~60℃

Charge

-25℃~60℃

Storage

-25℃~60℃

Max.Discharge Current

@ 25℃ 1200A(5s)

Capacity affected by Temperature (10 hour )

40℃

108%

25℃

100%

0℃

90%

-15℃

70%

Self-Discharge @ 25℃per Month

3%

Charge (Constant Voltage) @ 25℃

Standby Use

Initial Charging Current Less than 45.0A Voltage 13.6 - 13.8V

Cycle Use

Initial Charging Current Less than 45.0A Voltage 13.6 - 13.8V

Dimension (mm*mm*mm)

Length 532±1 * Width 206±1 * Height 215±1 (Total Height 219±1)

Weight (kg)

58.6±3%

a maintenance free battery wholesalea maintenance free battery manufacturers200ah 12v battery

Deep Cycle Gel Battery12v 200ah deep cycle gel battery

CSPOWER a maintenance free battery,
Due to its own structural advantages, the consumption of electrolytes is very small, and there is basically no need to supplement distilled water during service life. It has the characteristics of shock resistance, high-temperature resistance, small size, and small self-discharge.
CSPOWER a maintenance free battery 12V 200Ah deep-cycle gel solar battery has excellent performance and reliable quality. Welcome inquire!
